- Overview
● More beautiful
1. The use of professional industrial design methods, so that the vehicle appearance design is beautiful at the same time, but also prominent sense of force.
● More energy efficient
1. Equipped with 345.6V high voltage platform, the vehicle current is smaller and the heat loss is lower. Under the same conditions, the one-hour "energy consumption test" of conventional 80V lithium battery saves 12% energy and improves the efficiency by 14%;
2. The VCU controller can intelligently dispatch the lifting and walking drive system of the whole machine, and the energy loss is low.
● More efficient
1. Drive and lift are more efficient automotive permanent magnet synchronous motor, space vector control system, high power density, high motor efficiency;
2. The selection of large-capacity battery, combined with fast charging technology, the whole machine can meet the all-weather, high-intensity operation requirements.
● Faster
1. Standard 1C super fast charge technology, standard battery heating technology. It can be filled in an hour.
● More convenient
1. Can share charging pile with electric vehicle, can also choose portable charger, charging is convenient and economical;
2. The instrument layout is reasonable, and the motion state of the vehicle can be observed at a glance. Intelligent LCD screen, accurately display the whole machine status information. Drivers and maintainers can easily troubleshoot, reduce downtime and improve efficiency;
3. The special control locking structure and side plate structure design make the battery maintenance very convenient.
● More excellent
1. The driving and lifting system adopts a permanent magnet synchronous motor that can also provide large torque at low speed, and the large speed ratio reducer makes the driving speed, climbing grade and acceleration performance of the whole machine comparable to that of internal combustion forklift;
2. Non-contact regenerative braking is adopted, which is greatly simplified than the traditional braking system. Regardless of whether the driver brakes by stepping on the brake pedal or changing the direction of travel, the motor will be in a state of power generation, and its electromagnetic torque will become the braking torque. This means that wear on the brake pads is minimized and mechanical wear is greatly reduced. At the same time, the electricity generated is sent back to the battery to charge the battery and extend the working time of the battery.
● More secure
1. Motor, electronic control, high pressure components can reach IP67 dustproof, waterproof high protection level, can be used in cold storage, rainstorm, waterlogging road and other harsh conditions;
2. The electrical system is equipped with high-voltage interlock, insulation detection, over-voltage, over-current, over-temperature and other protection functions, which can intelligently provide security;
3.MSD maintenance switch can be powered off with one key, so that maintenance more peace of mind.
● More comfortable
1. Optimize the ergonomic design of the vehicle, so that the comfort of the product has been greatly improved, so that you can enjoy a comfortable operating experience;
2. Small diameter steering wheel (adjustable Angle) and double handle sedan combination switch greatly improve the comfort of the driver's operation.
● More reliable
1. The battery sinking design is adopted to ensure the stability of the whole machine;
2. The small front suspension design improves the longitudinal stability, and the high rear axle structure improves the transverse stability of the whole machine.
